FALL ARREST

FALL ARREST COMPACT FALL ARRESTER FA20 103 00A

 Blocker, Fall Arrester on polyamide kernmantle rope, multi-use
 Material : Aluminium
 Breaking strength : > 15 kN
 Connector : 1 steel screw-locking karabiner FA 50 101 17
 Works on 11 mm diameter anchorage line (Polyamide Kernmantle rope).
 Steel Karabiner FA 50 101 17 as an attachment element.
 Has a manual locked position to allow work on inclined roof, and also restraint
positioning (EN358).
 Very simple opening-closing system
 EN353-2:2002
Product Code Size
PHA168FA

OLYMPE CABLE, RETRACTABLE FALL ARRESTER
20 M WITH INTEGRATED RESCUE WINCH
FA20 401 20
 Wire rope diametre: 4.5 mm
 Length: 20 mtr
 Weight: 9.20 kg
 Breaking strength: > 12 kN
 Connectors: Swivel and FA 50 101 17 at anchorage end, FA 50 203 20 connector
with load indicator at attachment end
 Approved for a user with a max. weight of 140 kg in vertical use
 Olympe cable, Casing made up of high impact strength Polymer, to prevent breakage
 Comes with Galvanized Steel Wire Rope of diam 4.5 mm. FA 50 101 17 at
anchorage end and FA 50 203 20 at attachment end
 EN360:2002, EN1496:2017 class B, ATEX Directive 2014/34/EU
Product Code Size
PHA150FA 20

LOAD ARRESTER (MAXI 500 KG) LA10 500 10
 Load arrester with galvanized steel wire rope length 10 mtr designed to stop the fall
of a 500 kg maxi weight load
 Length of the wire rope : 10 metres
 Load Capacity : 500 kg
 Weight : 11.65 kg
 Diametre of the wire rope : 6 mm
 Breaking strength : > 7 kN
 Casing made up of high impact strength Polymer, to prevent breakage and is nearly
indestructible
 Multi-ratchet quick fall arrest system
 Integrated energy absorber, which reduces the efforts on the structure
 Reduced fall arrest distance
 Maximum 60 cycles per day
 Conforms to : 2006/42/CE
Product Code Size
PHA226FA 10m
