FALL ARREST

ATEX ANTISTATIC RESTRAINT WEBBING
FALL ARREST WEBBING LANYARD CONNECTOR FA50 207 55
ENERGY ABSORBING
LANYARD 1.50 MTR WITH
FA30 306 20
 Length : 1.50 mtr
 44 mm wide webbing Energy Absorber
which reduces the impact of the fall less
FA5020755 at one end
than 6 KN  Connectors : 1 steel scaffold hook
 Breaking strength : 22 kN
 Connectors - 1 aluminum scaffold hook  Conforms to : EN354:2010
double action, opening 60 mm, and 1  Made up of 30 mm wide polyester webbing
aluminum screw-locking karabiner, opening  Loops protected by an abrasion resistant
22 mm tubular webbing
 Lanyard : polyester with antistatic properties
 Absorber : polyamide and polyester with
antistatic properties
 Connectors : aluminum
 EN355 : 2002, EN1149-1 : 2006, EN13463-1
(2001) and EN136463-5 (2006)
 Can be used in ATEX atmosphere (zone 1).
Product Code Size Product Code Size
PHA03FA 2m PHA201FA 1.5m
RESTRAINT WEBBING RESTRAINT KERNMANTLE
LANYARD 1.5 MTR ROPE LANYARD 2 MTR
WITH CONNECTORS WITH CONNECTORS
FA40 303 15 FA40 503 20
 Made up of 30 mm wide polyester webbing  Length : 2 mtr
 Loops protected by an abrasion resistant  Connectors : 1 steel snap hook FA5020217
tubular webbing at one end and 1 steel scaffold hook
 Connectors : 1 steel snap hook FA5020217 FA5020755 at the other end
at one end and 1 steel scaffold hook  Breaking strength : 22 kN
FA5020755 at the other end  Made up of 11 mm diam polyamide
 Length : 1.50 mtr kernmantle rope
 Breaking strength: 22 kN  Abrasion resistant thimble to protect the
 EN354:2010 loops from being damaged by metallic
contact
 Sewing protected with a strong transparent
covering sleeve
 EN354:2010
Product Code Size Product Code Size
PLN05FA 1.5m PHA44FA 2m
FORKED ENERGY KERNMANTLE ROPE
ABSORBING TWISTED ANCHOR LINE 10M
ROPE LANYARD 1.50 MTR FA20 10 310
AND CONNECTORS  Kernmantle rope anchor line 10m for
FA30 200 15 sliding fall arrester FA 20 103 00A and FA
20 103 00B
 Fall indicator label
 Connectors : 1 steel screw-locking karabiner  Abrasion resistant thimble at the upper end
and stop knot at the lower end.
FA5010117 at one end and 2 steel scaffold  Spliced end is protected with a strong
hooks FA5020755 at the other ends transparent covering sleeve.
 Energy absorber in 44 mm wide webbing to  Colour tracer strand losing colour that
reduce the impact of the fall (less than 6 kN)
 Made up of 12 mm diam polyamide twisted shows the rope is unfit for use.
rope lanyard  Material: Polyamide
 Loops protected by an abrasion resistant  Diametre: 11 mm
thimble  Length: 10 m
 EN355:2002 and tested as per VG11 of PPE  EN 353-2:2002.
Directive 89/686/EEC
Product Code Size Product Code Size
PHA131FA 1.5m PHA167FA 10m
