FALL ARREST

FALL ARREST SUSPENSION TRAUMA RELIEF STRAP FA10 901 00

 Extremely effective, specially designed to help relieve the negative effects of
suspension trauma.
 Compact and light-weight. Does not hamper the activity of worker while at work.
 Allows the suspended worker to stand up in his harness to relieve pressure.
 Easy to attach to the harness with the help of the textile loop and velcro provided.
 Easy deployment ; operation is fool-proof.
 Size: Universal
 Weight: 0,086 kg
 Strap material : Polyester
 Buckle material : Steel
Product Code Size
PHA117FA One

4 USER HORIZONTAL TEMPORARY LIFELINE,
WITH 4 O-RINGS FA60 007 01
 Temporary and reusable lifeline specially designed to provide a suitable and safe
anchorage to 1, 2, 3 or 4 users at the same time while working.
 Total available length: 25 m. Minimum length: 5 m.
 Kernmantle rope (16 mm diam.) equipped with specially designed tensioner that
allows tensioning of lifeline between the two supports.
 Has a brass swivel-type end specially designed to prevent any twisting of the rope
during the use. Has a stop-knot secured with protective sleeve at the other end, to
prevent the rope from accidentally moving out of the tensioner.
 Provided with 2 steel Triple action-locking Karabiners with a 21 mm gate opening
(ref. FA 50 301 23), 2 anchorage webbing slings (lg. 2 m) and a transport bag FA 90
107 00.
 Has 4 Forged steel O-Rings for attaching the fall arrest system of each user.
 Tensioner : Aluminium and Stainless Steel
 Swivel-type end: Stainless Steel
 Connector : Steel
 Weight: 11.64 kg.
 Regulation (EU) 2016/425 Annex II using EN 795:2012, TS 16415:2013 Type C.
Product Code Size
PHA07FA 5m
